OD mm L1*L2

Frame T mm

H mm

Cover T1 mm

Pres. Bar

430*330

8

75

3

0 - 3

435*335

10

75

3

0 - 3

450*350

10

75

3

0 - 3

530*430

10

75

3

0 - 3

535*435

12

75

3

0 - 3

635*525

12

80

3

0 - 3

Height and Frame T can be chnaged accoring to your requirment.

Gasket: Silicone/EPDM/NBR/FPM in accordance with FDA 177.2600.

Material: 304(1.4301),316L(1.4404)

Height(B): 75, 80, 140, 150,180mmetc.

Internal surface: 0.8μm-0.5μm.

Outside surface: Mirror polished, Matte, sand-blasting finished.

Type

Size

Material

Inner Surf.

Outer Surf.

Qty

handl.

Height

Gasket

WZC

430*330

1.4301

0.5μm

Matte

20

1 Stainless

75mm

EPDM
